Product Description

Triangular Beam Structure

Gantry & Beam Structural Advantages

  • A
    The triangular beam with super large section can maximize the rigidity of the beam while reducing the weight of the beam.
  • B
    The gantry can be delivered modularly without disassembling the beam to avoid the loss of precision caused by the disassembly of the beam.
  • C
    Equipped with light curtain protection to prevent the machine gantry from colliding with workers.
  • D
    With the self-adaptive adjustment function on the left and right sides of the gantry, even if there is an error in the on-site assembly accuracy of the customer, the self-adaptive adjustment function can ensure the cutting accuracy to the greatest extent.

Enclosed Smoke Control & Adsorption System

1. Full 360° Adsorption
Strong multidirectional absorption forces waste dust downwards immediately.
2. Enclosed Extraction
Fully enclosed smoke control minimizes environmental particulate escape.
3. Smart Sensing
Automatically senses cutting head position to direct extraction localized focus.
In the dust area, the waste trolley and the middle partition form a closed environment, and the air valve is used for partition dust removal, and the sealing performance is good, ensuring that the large-format open model machine still has a strong dust removal effect.
Dust Extraction System
Aviation Aluminum Beam

Integrated Aviation Aluminum Beam

  • 3
    Adopted the integrated aviation aluminum beam reduces the weight of the beam and maximizes the rigidity of the beam.

Z-axis Fully Enclosed Protection

The Z-axis adopts a fully enclosed design, which effectively prevents cutting dust from entering the Z-axis screw and improves the service life of the screw.

Z-axis Enclosure
Application Materials
Fiber Laser Metal Cutting Machine is suitable for metal cutting like Stainless Steel Sheet, Mild Steel Plate, Carbon Steel Sheet, Alloy Steel Plate, Spring steel Sheet, Iron Plate, Galvanized Iron, Galvanized Sheet, Aluminum Plate, Copper Sheet, Brass Sheet, Bronze Plate, Gold Plate, Silver Plate, Titanium Plate, Metal Sheet, Metal Plate, etc.
Application Industries
Fiber Laser Cutting Machines are widely used in manufacture Billboard, Advertising, Signs, Signage, Metal Letters, LED Letters, Kitchen Ware, Advertising Letters, Sheet Metal Processing, Metals Components and Parts, Ironware, Chassis, Racks & Cabinets Processing, Metal crafts, metal art ware, elevator panel cutting, hardware, auto parts, Glasses Frame, Electronic Parts, Nameplates, etc.
Safety Mechanism Part 1 Safety Mechanism Part 2

Lubrication & Safety Buffers

  • A
    The waste lubricating oil recovery mechanism is equipped everywhere to prevent the accumulation of lubricating waste oil and cause fire hazards.
  • B
    Gear lubrication: The felt wheel lubrication is standard, which can fully lubricate the gears and improve the service life of the gears.
  • C
    The hard limit adopts a buffer structure to prevent the loss of precision caused by collision.

Technical Configurations & Spec Parameters

Model Number
LX12025LD
Lead Time
20-40 working days
Payment Terms
T/T; Trade Assurance; West Union; Paypal; L/C
Shipping Options
By sea / By land
Machine Model LX12025LD LX12020LD LX16030LD LX20030LD LX24030LD
Working Area (mm) 12100*2550 12100*2050 16500*3200 20500*3200 24500*3200
Power of Generator 1kw - 20kw
X/Y-axis Positioning Accuracy 0.02mm/m
X/Y-axis Repositioning Accuracy 0.01mm/m
X/Y-axis Max. Linkage Speed 80m/min
metal cutting by laser laser cut metals laser cutting for metal laser cut on metal cut sheet metal

Frequently Asked Questions

Q: What makes the triangular beam design superior to standard beam shapes?
The triangular beam features a super large cross-section that optimizes structural geometry. This setup achieves maximum beam rigidity while minimizing physical weight, leading to faster acceleration speeds and precision cutting.
Q: How does the machine handle the assembly inaccuracies on site?
The machine features a self-adaptive adjustment mechanism integrated on the left and right sides of the gantry. Even if slight assembly errors occur during setup on customer premises, the adaptive adjustment compensates automatically to safeguard optimal cutting precision.
Q: Is the dust extraction system suitable for large format cutting?
Yes. The system utilizes partition air valves along with a waste trolley and middle partition to establish a closed environment. This configuration guarantees highly concentrated 360° adsorption and smoke control, providing strong dust removal even for large-format open setups.
Q: What safety systems protect the operator and components from damage?
Safety features include light curtain protection sensors around the gantry to prevent worker collisions. Furthermore, the Z-axis screw is fully enclosed to stop dust entry, and hard travel limits are buffered to mitigate impact damage in case of over-travel.
Q: How is the gear mechanism maintained?
Standard configurations include a specialized felt wheel lubrication system that delivers continuous oil coverage to the gear components. Additionally, a comprehensive waste lubricating oil recovery system gathers runoff to prevent accumulation and decrease fire hazards.
Q: What metals and industries is this laser cutting machine suited for?
It cuts stainless steel, carbon steel, spring steel, galvanized sheets, copper, brass, aluminum, titanium, and more. It is heavily utilized in sheet metal processing, auto parts, elevators, sign manufacturing, and chassis cabinet production.
