The Segmented Rectangle Laser Tube Welded Bed
- Good rigidity, high precision, no deformation during the life cycle.
- Welded aluminum collet board, formed through high precision process.
- Good weight and good dynamic performance.
Pneumatic Chuck Clamping Design
It adopts an pneumatic clamp design on both sides and it can modulate the center automatically. The diagonal adjustable range is 20-220mm (320/350 is optional).
Professional Clamp Design
- Automatic pneumatic chuck, adjustable and stable, clamping range is wider and clamping force is larger.
- Non-destructive pipe clamping, fast automatic centering and clamping pipe, performance is more stable.
- The chuck size is smaller, rotation inertia is low, and dynamic performance is strong.
- Self-centering pneumatic chuck, gear transmission mode, higher transmission efficiency, long working life and high work reliability.
Fractional Automatic Support Installation
It employs intelligent tube support design, which can solve the deformation problems in the process of long tube cutting.
Installation Autofocus
It will automatically in cutting process adjust the focus which can realize the best cutting effect of different thickness of metal.
| Technical Specifications |
| Model |
LX122TX Fiber laser cutting machine |
| Laser Power |
1-20KW |
| Max Holding diameter |
20-220mm |
| Laser Wave Length |
1064nm |
| Maximum Idle Running Speed |
60m/min |
| Maximum acceleration |
1.2G |
| Position Accuracy |
±0.03mm/m |
| Repeat Positional Accuracy |
±0.05mm |
| Working life of fiber module |
More than 100000 hours |
| Working Voltage |
380V/50Hz |
| Work Environment |
0-45°C, Moisture 45-85% |
Samples
Factory
Our Service
Customer Visit
Off-line Activity
FAQ
Do you have CE document and other documents for customs clearance?
Yes, we have original certificates. Initially we will show you and after shipment we will give you CE / Packing list / Commercial Invoice / Sales contract for customs clearance.
What are the available payment terms?
We accept TT, West Union, PayPal, LC, Cash and other standard payment methods.
I don't know how to use it after I receive it or I have problems during use, what should I do?
We can provide support via TeamViewer, WhatsApp, Email, Phone, and Skype with video till all of your problems are resolved. We can also provide on-site door service if required.
I don't know which machine model is suitable for me?
Just share the following information with us:
1) Max work size: to choose the most suitable model.
2) Materials and cutting thickness: to determine the required power of the laser generator.
3) Business industry: we can provide optimized advice based on extensive industry experience.
What materials can this fiber laser cutting machine process?
This fiber laser cutting machine is specifically designed for cutting various metal tubes and pipes, including carbon steel, stainless steel, aluminum, brass, and copper.
How is the laser cutting machine packaged for transport?
The machine is carefully wrapped and packaged in high-strength, export-standard wooden cases, ensuring maximum protection against moisture, rust, and physical impacts during transit.
