Product Description

Bending Machine Structure
The motor, hydraulic pump and valve group are installed under the oil tank, and the motor drives the pump body to supply pressure oil. The valve group is controlled by the electric hydraulic system to realize the rise of the workbench driven by the oil cylinder.
The lower table fall is a natural fall relying on its own weight, fast, stable and safe.
The hydraulic system design comes from the three-cylinder oil circuit design of the Japanese bending machine, and the hydraulic components of the same quality are assembled to reduce the hydraulic pipeline, so that the bending has a high degree of reliability and quality requirements.
High bending accuracy. Angle accuracy can reach ±0.5
High bending speed, up and down fast forward can reach 58mm/s, bending speed to 12mm/s.
With sufficient pressure and pressure holding capacity, to achieve the bending of various materials such as thick plate and stainless steel.
The starting height of the lower table can be arbitrarily set to facilitate for quick bending.
The cylinder works only when it is bent and falls back naturally when it is lowered. Energy saving than the traditional dynamic hydraulic type.
When bending the working movement, the operator is easy to perceive the working state, improve safety.
Master cylinder capacity 50L
Feed speed 58 mm / s
Return speed 46 mm / s
Bending velocity 0--10 mm / s
Bending Angle accuracy ±0.5 °
Back stroke 450 mm
Back gauge forward and backward accuracy ±0.01 mm
Main motor power 5.5KW
Lower table travel 100 mm
Control axes 2
Bending Process Diagram
Product Display & Services
Samples
Samples
Packaging
Packaging
Factory Showcase
Factory
Our Service
Our Service
Customer Visit
Customer Visit
Off-line Activity
Off-line Activity
Frequently Asked Questions
Do you have CE document and other documents for customs clearance?
Yes, we have CE, Provide you with a one-stop service. At first we will show you and after shipment we will give you CE/Packing list/Commercial Invoice/ Sales contract for customs clearance.
If we are interested in your machine, how do we choose?
Could you tell me your materials: cs or ss and their thickness? And the biggest bending width? Then we will confirm the machine model for you.
How about warranty?
3 years quality guaranty, the machine with main parts (excluding the consumables) shall be changed free of charge (some parts will be maintained) when if any problem during the warranty period.
Do you have after sales support?
Yes, we are happy to give advice and we also have skilled technicians available across the world, We need your machines running in order to keep your business running.
Do you have any other machine style?
Yes, please check the following machine style, if you have any questions, you can contact us any time, 24x7, we always here.
