A convex wedge consists of a set of convex oblique wedges with a beveled surface. Each protruding wedge is designed by finite element analysis according to the deflection curve of the slide and worktable.

The CNC controller system calculates the required compensation amount based on the load force. This force causes deflection and deformation of the vertical plates of the slide and table, and automatically controls the relative movement of the convex wedge, so as to effectively compensate for the deflection deformation caused by the slider and the table riser, and obtain the ideal bending workpiece.

Adopt 2-v quick change clamping for bottom die.

Lasersafe PSC-OHS safety guard, communication between CNC controller and safety control module.

Dual beam from protection point below 4mm below the tip of upper tool, to protect operator`s fingers; three regions (front, middle and real) of laser can be flexibly closed, ensure complex box bending processing; mute point is 6mm, to realize efficient and safe production.

• When mark bending, the support plate can realize the function of turning over following. Following angle and speed are calculated and controlled by CNC controller, moving along linear guide left and right.
• Adjust the height up and down by hand; front and rear can also be adjusted manually to suit for different bottom die openings.
• Support platform can be brush or stainless steel tube. According to workpiece size, two supports linkage movement or separate movement can be chosen.

• TP10S Touch screen
• Support angle programming and depth programming switching
• Support settings of mold and product library
• Each step can set opening height freely
• The shift point position can be freely controlled
• It can realize Multi-axis expansion of Y1, Y2, R
• Support mechanical crowning working table control
• Support large circular arc automatic generate program
• Support top dead center, bottom dead center, loose foot, delay and other step change options, it improves processing efficiency effectively
• Support electromagnet simple bridge
• Support fully automatic pneumatic pallet bridge function
• Support automatic bending, realize unmanned bending control, and support up to 25 steps of automatic bending
• Support time control of valve group configuration function, fast down, slow down, return, unloading action and valve action
• It has 40 product libraries, each product library has 25 steps, large circular arc supports 99 steps

• Ball screw/liner guide are high precision
• Upper tool clamping device is fast clamp
• Multi-V bottom die with different openings
• Aluminium alloy material platform, attractive appearance, and decrease scratch of workpiece
