Product Description

💡

The function of the CO2 laser cutter focusing lens is to focus the laser light on one point, so that the laser energy per unit area reaches a large value, burning the workpiece quickly, and achieving the functions of cutting and engraving.

1390-M6 CO2 Laser Cutter Parameter

Model number	1390-M6
Working area	1300*900 mm
Laser tube type	Sealed CO2 glass laser tube
Laser tube dustproof grade	A
Platform type	blade/honeycomb/flat plate (optional depending on material)
Feeding height	30 mm
Engraving speed	0-100mm/s 60m
Cutting speed	0-500mm/s
Positioning accuracy	0.01mm
Laser tube power	40-180W
Continue working after power outage	√
Data transmission method	USB
Software	RDworks V8
Memory	128MB
Motion control system	Stepper motor drive/hybrid servo motor drive
Processing technology	engraving, relief, line drawing, cutting and dotting
Supported formats	JPG PNG BMP DXF PLT DSP DWG
Supports drawing software	Photoshop AutoCAD CoreLDRAW
Computer system	Windows10/8/7
Minimum engraving size	1*1mm
Application materials	Acrylic, wood board, leather, cloth, cardboard, rubber, two-color board, glass, marble and other non-metallic materials
Overall dimensions	191014101100mm
Voltage	AC220/50HZ (voltage can be customized according to country)
Rated power	1400-2600W
Total weight	420KG

Features of CO2 laser cutter

The frame is precision machined to ensure the optical path and accuracy.
The table and the machine tool are separated to solve the problem of machine tool deformation when the low-power cutting machine works for a long time.
The table surface is finished, which solves the problem of uneven table surface. The smooth table surface greatly improves the cutting accuracy during work and increases the service life.
Hidden transmission structure prevents dust and increases service life.
The integrated structure of the copper gear ensures accuracy and corrosion resistance.
The isolation board uses fireproof materials to reduce the risk of fire.
The material of the transmission part is upgraded from commonly used aluminum profiles to 6063-T5 high-strength aluminum profiles, which reduces the weight of the beam and improves the strength of the beam.
Fire protection device to reduce the risk of fire.

Consumable parts

1. Focusing lens

Depends on maintenance, usually replace one lens every three months.

2. Reflective lenses

Depends on maintenance, usually replaced every three months.

3. Laser tube

Lifespan is 9,000 hours (In other words, if you use it 8 hours a day, it can last about three years), replacement cost depends on power.

Factory Workshop

Our Service

Customer Visit

Global customers visit exhibition center

Off-line Activity

Exhibition events and customer offline interactions

CO2 laser generator is a gas molecular laser, co2 is used as the medium, and the light beam is transmitted through the co2 laser mirror.

Border patrol camera on mixed cut

Frequently Asked Questions

Q Do you have CE document and other documents for customs clearance?

Yes, we have original files. At first we will show you and after shipment we will give you CE / Packing list / Commercial Invoice / Sales contract for customs clearance.

Q What are the accepted payment terms?

We accept TT, West Union, PayPal, LC, Cash, and other standard payment methods.

Q I don't know how to use the machine after I receive it, or I have problems during use. What should I do?

We can provide remote assistance via TeamViewer, WhatsApp, Email, Phone, or Skype with camera setup until all your issues are resolved. We can also provide door-to-door service if needed.

Q I don't know which model is suitable for me. How can I choose?

Just tell us the following information:
1) Max work size: to choose the most suitable model size.
2) Materials and cutting thickness: to choose the correct power of the laser generator.
3) Business industries: we can share insights and offer specific recommendations based on our industry experience.

Q What kinds of materials can the CO2 laser cutter process?

It is suitable for processing non-metallic materials such as Acrylic, wood board, leather, cloth, cardboard, rubber, two-color board, glass, marble, and others.

Q How long do the consumable parts like the laser tube and lenses last?

The laser tube has a lifespan of approximately 9,000 hours (about 3 years if operated 8 hours a day). The focusing lens and reflective lenses generally need replacement every three months depending on proper maintenance.
