| Laser Type Characteristic | Unit | LXC-100W Value |
|---|---|---|
| M² | <2 | |
| Delivery Cable Length | m | 5 |
| Average Output Power | W | >100 |
| Maximum Pulse Energy | mJ | 1.5 |
| Pulse Frequency Range | kHz | 1-4000 |
| Pulse Width | ns | 2-500 |
| Output Power Instability | % | <5 |
| Cooling Method | Air Cooled | |
| Power Supply Voltage | V | 48V |
| Power Consumption | W | <400 |
| Power supply current requirement | A | >8 |
| Central Wavelength | nm | 1064 |
| Emission Bandwidth (FWHM) @3dB | nm | <15 |
| Polarization | Random | |
| Anti-Reflection Protection | Yes | |
| Output Beam Diameter | mm | 4.0±0.5, 7.5±0.5 (Customizable) |
| Output Power Tuning Range | % | 0～100 |
| Ambient Temperature Range | ℃ | 0～40 |
| Storage Temperature Range | ℃ | -10～60 |
| Dimensions | mm | 617*469*291 |
| Weight | Kg | 28 |
